Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock


Model and Suffix Codes of Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock
Model: AAI143 - Analog Input Module (4 to 20 mA, 16-channel, Isolated)
YOKOGAWA AAI143-H53 Analog Input Module Suffix Codes:
-H - With digital communication (HART Protocol)
5 - With no explosion protection
3 - With ISA Standard G3 option and temperature (-20 to 70°C) option
Estimated Lead Time: 7 - 10 Working Days
Shipping Weight: 2 Kg
Specifications of Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock
This GS covers the hardware specifications of the Analog I/O Modules (FIO) that can be installed in the Node Unit
for ESB Bus (ANB10S, ANB10D), the Node Unit for ER Bus (ANR10S, ANR10D) and Compact Field Control Unit
(for FIO) (AFF50S, AFF50D, AFV10S, AFV10D).
These modules mainly receive 4 to 20 mA DC or 1 to 5 V DC standardized signal from 2-wire/4-wire transmitters.
They can be used in dual redundant configuration.

STANDARD SPECIFICATIONS of Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock


   Current/Voltage Input Modules (Non-Isolated)
  These modules provide 16 inputs of mainly 4 to 20 mA DC or 1 to 5 V DC standardized signals from 2-wire/4-wire transmitters.
  They can be used in dual-redundant configuration.



     Current Input Modules (Isolated)

     AAI143 provides 16 inputs of 4 to 20 mA signal. It can be used in dual-redundant configuration.

Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock

Items Specifications
Model AAI143 (*1)
Number of input channels 16, isolated
Input signal 4 to 20 mA
Allowable input current 24 mA
Input resistance Power ON 270 Ω (20 mA) to 350 Ω (4 mA) (*2)
  Power OFF 500 kΩ or larger
Accuracy ±16 μA
Data update period 10 ms
Transmitter power supply 19.0 V or higher (at 20 mA) 25.5 V or less (at 0 mA) (output current limit: 25 mA) (*5)
Setting of 2-wire or 4-wire transmitter For each channel by setting pin
Drift due to ambient temperature change ±16 μA/10 C
Maximum current consumption 230 mA (5 V DC), 540 mA (24 V DC)
Weight 0.3 kg
External communication Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
HART communication (*3) Available


MODEL AND SUFFIX CODES of Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock


Model AAI143    Analog Input Module (4 to 20 mA, 16-channel, Isolated)
  -S Standard Type
  -H With digital communication (HART protocol)
   5 With no explosion protection
     E With explosion protection
        0 Basic type
        3 With ISA Standard G3 option and temperature (-20 to 70 °C) option
/K4A00 With KS Cable Interface Adapter [Model : ATK4A-00]
  /A4S00 With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00]
  /A4S10 With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10]
  /A4D00 With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00]
  /A4D10 With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10]
  /CCC01 With Connector Cover for MIL Cable [Model : ACCC01]

Ordering Models of Yokogawa AAI143-H53 AAI143-H50 AAI143-H00 Analog Input Module In Stock
AAI143-S50/K4A00, AAI143-S50/A4S00, AAI143-S50/A4S10, AAI143-S50/A4D00, AAI143-S50/A4D10, AAI143-S50/CCC01,
AAI143-S53/K4A00, AAI143-S53/A4S00, AAI143-S53/A4S10, AAI143-S53/A4D00, AAI143-S53/A4D10, AAI143-S53/CCC01,
AAI143-SE0/K4A00, AAI143-SE0/A4S00, AAI143-SE0/A4S10, AAI143-SE0/A4D00, AAI143-SE0/A4D10, AAI143-SE0/CCC01,
AAI143-SE3/K4A00, AAI143-SE3/A4S00, AAI143-SE3/A4S10, AAI143-SE3/A4D00, AAI143-S53/A4D10, AAI143-S53/CCC01,
AAI143-H50/K4A00, AAI143-H50/A4S00, AAI143-H50/A4S10, AAI143-H50/A4D00, AAI143-h50/A4D10, AAI143-H50/CCC01,
AAI143-H53/K4A00, AAI143-H53/A4S00, AAI143-H53/A4S10, AAI143-H53/A4D00, AAI143-h53/A4D10, AAI143-H53/CCC01,
AAI143-HE0/K4A00, AAI143-HE0/A4S00, AAI143-HE0/A4S10, AAI143-HE0/A4D00, AAI143-HE0/A4D10, AAI143-HE0/CCC01,
AAI143-HE3/K4A00, AAI143-HE3/A4S00, AAI143-HE3/A4S10, AAI143-HE3/A4D00, AAI143-HE3/A4D10, AAI143-HE3/CCC01
