Endress+Hauser Levelflex FMP54 is a guided-wave radar level instrument designed for demanding high-temperature and high-pressure service. When purchasing FMP54-BCEEBBAED1AHJ+EBEHF4JAJBKEOAPBZ1 (LENGTH:2030MM), treat the full order code and 2030 mm probe length as one engineered package: probe construction, process connection, pressure class, wetted materials, temperature extension, communication, approvals and documentation must all be checked before release.
Order code: FMP54-BCEEBBAED1AHJ+EBEHF4JAJBKEOAPBZ1 (LENGTH:2030MM)
Measurement: continuous guided-radar level measurement in high-temperature and high-pressure processes
Buying priority: exact 2030 mm probe, pressure-temperature rating, gas-phase compensation requirement, delivery control and engineered replacement
Where FMP54 fits best
Endress+Hauser positions the Levelflex FMP54 for high-temperature and high-pressure applications in oil and gas, chemical and power plants. Its guided-wave radar principle is suited to demanding vessels, and gas-phase compensation is available for applications where changing vapor conditions can influence measurement.
The manufacturer’s published family specifications list rod and coaxial-probe accuracy of ±2 mm, process temperatures from −196 to +280 °C for XT versions and up to +450 °C for HT versions, and pressure from vacuum to 400 bar. Maximum measuring distance depends on probe type: up to 10 m for rod probes, 45 m for rope probes and 6 m for coaxial probes. These are family limits—not confirmation that every option is present in the quoted order code.
Procurement decision checklist
- Define the process envelope: normal and design temperature, operating and test pressure, vapor or steam conditions, dielectric constant, density, interface duty, turbulence and buildup.
- Lock the 2030 mm probe: confirm probe type, active length, reference point, insertion depth, nozzle geometry, bottom clearance and installation space.
- Confirm compensation needs: decide whether gas-phase compensation is required and verify the matching probe and process arrangement.
- Match mechanical construction: process connection, pressure class, seal concept, wetted materials and corrosion compatibility must fit the vessel and medium.
- Freeze electrical and approvals: confirm output protocol, power, housing, cable entry, hazardous-area approval, SIL requirements and documentation.
- Approve the exact code: release FMP54-BCEEBBAED1AHJ+EBEHF4JAJBKEOAPBZ1 (LENGTH:2030MM) only after the complete configured datasheet agrees with the purchase specification.
Lead-time management for critical service
The 2030 mm probe, high-temperature extension, pressure-rated connection, special materials, compensation arrangement, approvals, inspection and material certificates can each influence production time. A family-level stock answer is not enough for a shutdown-critical purchase.
Freeze technical requirements early, request a written delivery schedule against the exact order code and reserve time for drawing approval, certificate review, factory release, logistics, customs and site commissioning. If schedule risk appears, compare only technically approved alternatives; changing probe geometry, pressure class, material or approval to shorten lead time requires written engineering acceptance.
Replacing an old or discontinued level instrument
Begin with the installed nameplate, full order code and serial number. Record the probe style and length, process connection, design pressure and temperature, wetted materials, vapor conditions, approvals, output, power, parameters, DCS scaling and vessel geometry before proposing a successor.
- Confirm lifecycle status and collect the original datasheet, drawings, certificates and parameter backup.
- Compare measuring duty, probe geometry, pressure-temperature rating, mechanical fit, electrical interface and approvals line by line.
- Review whether gas-phase compensation or a different guided-radar arrangement is needed for the actual vapor space.
- Plan isolation, depressurization, installation, parameter migration, loop tests, alarm checks and process verification.
- Retain the old device and rollback plan until the replacement passes mechanical, electrical and measurement acceptance.
Important: FMP51, FMP52, FMP53, FMP54 and other Levelflex variants are not automatically interchangeable. A similar measuring principle does not guarantee the same pressure-temperature capability, probe construction, compensation, connection, materials, approvals or communication.
