Endress+Hauser Levelflex FMP53 is a guided-wave radar level instrument for hygienically sensitive food and life-science processes. When purchasing FMP53-AAACCADAB5TDJ L=560 mm, treat the complete order code and 560 mm rod length as one engineered configuration: process connection, wetted materials, surface and hygiene requirements, temperature, pressure, communication, approvals and documentation all need confirmation.
Order code: FMP53-AAACCADAB5TDJ L=560 mm
Measurement: continuous guided-radar level measurement in hygienic liquid applications
Buying priority: exact 560 mm rod, hygienic connection and certificates, delivery control and validated replacement
Where FMP53 fits best
Endress+Hauser positions the FMP53 for high hygiene requirements in food and life-science production. The rod-probe design is intended for reliable measurement with moving surfaces, foam, changing media and filling through a spray head. The manufacturer also highlights in-situ validation without removing the instrument from the process.
Published specifications list ±2 mm rod-probe accuracy, a measuring range up to 6 m, process temperature from −20 to +150 °C and pressure from vacuum to 16 bar. Hygienic connections can include Tri-Clamp, DIN 11851, DIN 11864-1, NEUMO, Varivent N and SMS. Main wetted materials include 304/304L/316L and PEEK, depending on configuration.
Procurement decision checklist
- Confirm the hygienic duty: product, CIP/SIP media, cleaning temperature, pressure cycle, foam, agitation and filling method.
- Lock the 560 mm rod: verify active length, insertion depth, vessel clearance, nozzle geometry and whether an electropolished or separable probe is required.
- Match the process connection: standard, size, seal material, surface finish, weld-in adapter and site hygienic practice must agree.
- Freeze compliance documents: specify 3-A, EHEDG, ASME BPE, USP Class VI, EN 10204 3.1, WHG/SIL or hazardous-area approvals only where required.
- Confirm integration: power, 4–20 mA HART, PROFIBUS PA or FOUNDATION Fieldbus, cable entry, display, Bluetooth and asset-management requirements.
- Approve the exact code: release FMP53-AAACCADAB5TDJ L=560 mm only after the complete coded configuration matches the approved datasheet.
Lead-time management for hygienic projects
Exact rod length, hygienic connection, surface treatment, seals, housing, protocol, approvals, material certificates and calibration or linearity documents can each affect production and inspection time. Request availability against the complete order code, not the FMP53 family name alone.
For shutdown or validation-critical work, freeze the configuration early and include time for document review, factory release, logistics, customs, site cleaning and commissioning. Keep technically approved alternatives ready, but never change the hygienic connection, seal, wetted material, probe finish or approval merely to gain a shorter lead time without written engineering and quality acceptance.
Replacing an old or discontinued hygienic level instrument
Start with the installed nameplate, full order code and serial number. Record the existing probe length, process connection, seal, surface finish, CIP/SIP conditions, approvals, protocol, cable entry, parameters, DCS scaling and validation documents before selecting a successor.
- Confirm lifecycle status and collect the original configuration, drawings, certificates and parameter backup.
- Compare probe, hygienic, mechanical, electrical, communication and approval requirements line by line.
- Check nozzle geometry, insertion depth, weld-in adapter, seal compatibility, cleaning access and installation clearance.
- Plan documentation approval, cleaning, calibration, parameter migration, loop tests, alarm checks and validation evidence.
- Retain the old device and rollback plan until the replacement passes leak, hygiene, functional and process verification.
Important: FMP51, FMP52, FMP53 and other Levelflex variants are not automatically interchangeable. A similar measuring principle does not guarantee the same hygienic design, process connection, wetted materials, probe construction, certificates or communication.
