Hirschmann 943898001: Long-Haul Gigabit Fiber for Industrial Networks

Model: M-SFP-LH/LC-EEC
Part number: 943898001

When an industrial Gigabit Ethernet link must extend well beyond standard LX or LX+ distances, the Hirschmann M-SFP-LH/LC-EEC provides a purpose-built long-haul optical interface. This compact SFP uses 1550 nm single-mode optics and a duplex LC connector for specified links from 23 to 80 km.

Key Specifications

Data rate	1 × 1000 Mbit/s
Connector	Duplex LC
Fiber	Single-mode 9/125 µm
Wavelength	1550 nm
Specified link length	23–80 km
Link budget	5–22 dB
Power	Supplied by the host switch
Diagnostics	Optical input/output power and transceiver temperature

Where an 80 km Industrial SFP Makes Sense

The module is designed for long fiber routes between substations, utility sites, transportation nodes, process facilities, remote pumping stations and geographically separated plant buildings. It preserves a Gigabit backbone where intermediate active equipment would add power, cabinet and maintenance requirements.

Critical Optical-Budget Check

This is not a universal replacement for shorter-range optics. The published optical budget begins at 5 dB and the example link range begins at 23 km. A short route may deliver excessive optical power to the receiver unless the link is engineered with suitable attenuation. Before ordering, calculate total fiber loss, connector loss, splice loss and design margin at 1550 nm.

Compatibility Before Purchase

• Confirm the exact Hirschmann host switch and software support M-SFP-LH/LC-EEC.
• Use a matching optical specification at the far end of the link.
• Verify single-mode 9/125 µm fiber and duplex LC connectivity.
• Confirm the host-device temperature range and required system approvals; these can limit the overall installation.
• Do not confuse 943898001 with the longer-reach M-SFP-LH+/LC EEC 942119001.

What to Send for a Fast Quote

Provide part number 943898001, quantity, host-switch model, link distance, measured or calculated link loss, fiber type, delivery country and required date. A photo of the existing switch label is useful for replacement projects.
