Hirschmann M-SFP-LX+/LC EEC 942024001
Hirschmann M-SFP-LX+/LC EEC: Long-Reach Gigabit Fiber
Model: M-SFP-LX+/LC EEC
Part number: 942024001
For industrial Ethernet routes beyond the reach of a conventional LX optic, the Hirschmann M-SFP-LX+/LC EEC provides a long-distance 1000 Mbit/s single-mode fiber interface in a compact SFP format. Its extended-temperature design makes it suitable for demanding network locations.
Verified Specifications
| Data rate | 1 × 1000 Mbit/s |
| Connector | Duplex LC |
| Fiber type | Single-mode 9/125 µm |
| Specified link length | 14–42 km |
| Link budget at 1310 nm | 5–20 dB |
| Operating temperature | −40 to +85°C |
| Power consumption | 1 W, supplied by the host switch |
| Diagnostics | Optical input/output power and transceiver temperature |
| Dimensions | 13.4 × 8.5 × 56.5 mm |
Where Long-Reach LX+ Adds Value
The module can connect distant control rooms, substations, utility sites, transportation nodes or plant buildings while preserving a Gigabit fiber backbone. Optical diagnostics help maintenance teams observe received/transmitted power and module temperature through a compatible managed switch.
Important Optical-Budget Warning
The published range begins at 14 km because the transceiver has a minimum link-budget requirement. A shorter route may need engineered attenuation to prevent receiver overload. Confirm the complete optical-loss calculation before commissioning; distance alone is not enough.
Quote and Compatibility Information
For a fast check, provide the host switch model, software version, link distance, fiber specification, connector/splice count, quantity and destination. We can then help distinguish 942024001 from the 20 km M-SFP-LX/LC EEC (943897001) and other Hirschmann optical options.
