Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
Product Description of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
TRIO POWER power supplies with standard functionality
TRIO POWER is particularly suited to standard machine production, thanks to 1- and 3-phase versions up to 960 W. The wide-range input and the international approval package enable worldwide use.
The robust metal housing, the high electric strength, and the wide temperature range ensure a high level of power supply reliability.
Your advantages of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
- Use the third negative terminal block as a grounding terminal block and minimize installation costs
- Rugged design with metal housing and wide temperature range from -25 to +70°C
- Maximum operational reliability thanks to high MTBF (mean time between failures) of more than 500,000 hours and high dielectric strength of up to 300 V AC
- Compensation of voltage drops by means of output voltage that can be adjusted on the front
Key Commercial Data of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Orderkey | 2902646 |
|---|---|
| Packing unit | 1 pc |
| GTIN | 4046356669672 |
| Weight per Piece (excluding packing) | 800.000 g |
| Custom tariff number | 85044030 |
| Country of origin | CN (China) |
Dimensions of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Width | 40 mm |
|---|---|
| Height | 130 mm |
| Depth | 115 mm |
Ambient conditions of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C ... 70 °C (> 55° C derating : 2.5%/K) |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Max. permissible relative humidity (operation) | ≤ 95 % (at 25 °C, non-condensing) |
| Noise immunity | EN 61000-6-2:2005 |
Input data of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Nominal input voltage range | 100 V AC ... 240 V AC |
|---|---|
| Input voltage range | 85 V AC ... 264 V AC (Derating < 90 V AC: 2.5 %/K) |
| Dielectric strength maximum | 300 V AC |
| AC frequency range | 45 Hz ... 65 Hz |
| Discharge current to PE | < 3.5 mA |
| Current consumption | 1 A (120 V AC) |
| 0.5 A (230 V AC) | |
| Nominal power consumption | > 12 V DC, constant capacity restricted |
| Inrush surge current | < 30 A |
| Power failure bypass | > 40 ms (120 V AC) |
| > 180 ms (230 V AC) | |
| Choice of suitable circuit breakers | 6 A ... 16 A (Characteristics B, C, D, K) |
| Type of protection | Transient surge protection |
| Protective circuit/component | Varistor |
Output data of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Nominal output voltage | 5 V DC ±1 % |
|---|---|
| Setting range of the output voltage (USet) | 4.5 V DC ... 6 V DC (> 12 V DC, constant capacity restricted) |
| Nominal output current (IN) | 10 A (-25°C ... 55°C) |
| Derating | 55 °C ... 70 °C (2.5%/K) |
| Connection in parallel | Yes, for redundancy and increased capacity |
| Connection in series | yes |
| Max. capacitive load | Unlimited |
| Active current limitation | Approx. 12 A (in the event of a short-circuit) |
| Control deviation | < 1 % (change in load, static 10 % ... 90 %) |
| < 2 % (change in load, dynamic 10 % ... 90 %) | |
| < 0.1 % (change in input voltage ±10 %) | |
| Residual ripple | < 60 mVPP |
| Output power | 50 W |
| Typical response time | < 1 s |
| Peak switching voltages nominal load | < 70 mVPP |
| Maximum power dissipation in no-load condition | 1.5 W |
| Power loss nominal load max. | 13.5 W |
General of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Net weight | 0.6 kg |
|---|---|
| Efficiency | > 80 % (230 V AC) |
| Insulation voltage input/output | 4 kV AC (type test) |
| 2 kV AC (routine test) | |
| Insulation voltage input / PE | 2 kV AC (type test) |
| 2 kV AC (routine test) | |
| Insulation voltage output / PE | 500 V DC (routine test) |
| Protection class | I |
| MTBF (IEC 61709, SN 29500) | > 500000 h |
| Mounting position | horizontal DIN rail NS 35, EN 60715 |
| Assembly instructions | Can be aligned: Horizontally 0 mm, vertically 50 mm |
Connection data, input of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Connection method | Screw connection |
|---|---|
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Stripping length | 9 mm |
| Screw thread | M2,5 |
Connection data, output of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Connection method | Screw connection |
|---|---|
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Stripping length | 9 mm |
| Screw thread | M2,5 |
Standards and Regulations of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
|---|---|
| Shock | 15g in all directions in acc. with IEC 60068-2-27 |
| Noise immunity | EN 61000-6-2:2005 |
| Standards/regulations | EN 61000-4-2 |
| Contact discharge | 6 kV |
| Standards/regulations | EN 61000-4-3 |
| Frequency range | 80 MHz ... 3 GHz |
| Test field strength | 10 V/m |
| Standards/regulations | EN 61000-4-4 |
| Comments | Criterion B |
| Standards/regulations | EN 61000-4-5 |
| EN 61000-6-3 | |
| EN 61000-4-6 | |
| Frequency range | 10 kHz ... 80 MHz |
| Voltage | 10 V |
| Standards/regulations | EN 61000-4-11 |
| Standard - Safety of transformers | EN 61558-2-17 |
| Standard - Electrical safety | EN 60950-1/VDE 0805 (SELV) |
| EN 61558-2-17 | |
| Standard – Electronic equipment for use in electrical power installations and their assembly into electrical power installations | EN 50178/VDE 0160 (PELV) |
| Standard – Safety extra-low voltage | EN 60950-1 (SELV) |
| EN 60204 (PELV) | |
| Standard - Safe isolation | DIN VDE 0100-410 |
| Standard – Protection against shock currents, basic requirements for protective separation in electrical equipment | EN 50178 |
| Standard – Limitation of mains harmonic currents | EN 61000-3-2 |
| UL approvals | UL/C-UL listed UL 508 |
| UL/C-UL Recognized UL 60950 | |
| Vibration (operation) | < 15 Hz, amplitude ±2.5 mm (according to IEC 60068-2-6) |
| 15 Hz ... 150 Hz, 2.3g, 90 min. | |
| Low Voltage Directive | Conformance with LV directive 2006/95/EC |
| Rail applications | EN 50121-4 |
Classifications of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
eCl@ss
| eCl@ss 4.0 | 27040702 |
|---|---|
| eCl@ss 4.1 | 27040702 |
| eCl@ss 5.0 | 27242213 |
| eCl@ss 5.1 | 27049002 |
| eCl@ss 6.0 | 27049002 |
| eCl@ss 7.0 | 27049002 |
| eCl@ss 8.0 | 27049002 |
| eCl@ss 9.0 | 27040701 |
ETIM of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| ETIM 3.0 | EC001039 |
|---|---|
| ETIM 4.0 | EC002540 |
| ETIM 5.0 | EC002540 |
| ETIM 6.0 | EC002540 |
UNSPSC of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
| UNSPSC 6.01 | 30211502 |
|---|---|
| UNSPSC 7.0901 | 39121004 |
| UNSPSC 11 | 39121004 |
| UNSPSC 12.01 | 39121004 |
| UNSPSC 13.2 | 39121004 |
Product list TRIO POWER of Phoenix Contact TRIO-PS600DC24DC20 2866530 Power Supply Unit
TRIO-PS-2G/1AC/24DC/5 - 2903148
TRIO-PS-2G/1AC/24DC/10 - 2903149
TRIO-PS-2G/1AC/24DC/20 - 2903151
TRIO-PS-2G/1AC/12DC/10 - 2903158
TRIO-PS-2G/1AC/48DC/5 - 2903159
TRIO-PS-2G/1AC/48DC/10 - 2903160
TRIO-PS-2G/1AC/24DC/3/C2LPS - 2903147
TRIO-PS-2G/1AC/12DC/5/C2LPS - 2903157
TRIO-PS-2G/1AC/24DC/5/B+D - 2903144
TRIO-PS-2G/1AC/24DC/10/B+D - 2903145
TRIO-PS-2G/3AC/24DC/5 - 2903153
TRIO-PS-2G/3AC/24DC/10 - 2903154
TRIO-PS-2G/3AC/24DC/20 - 2903155
TRIO-PS/600DC/24DC/20 - 2866530
TRIO-PS/3AC/24DC/40 - 2866404
TRIO-PS/1AC/5DC/10 - 2902646
TRIO-PS/1AC/12DC/ 5 - 2866475
TRIO-PS/1AC/12DC/10 - 2866488
TRIO-PS/1AC/48DC/ 5 - 2866491
TRIO-PS/1AC/48DC/10 - 2866501
