IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-

description:IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock ...
BASIC INFO
IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock






Application of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Application for Pt100 and Pt1000 measuring elements
Electrical data of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Operating voltage [V] 18...32 DC; (cULus - Class 2 source required)
Current consumption [mA] < 50
Protection class III
Reverse polarity protection yes
Power-on delay time [s] 1
Integrated watchdog yes
Inputs / outputs of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Number of inputs and outputs Number of digital outputs: 2
Outputs of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Total number of outputs 2
Output signal switching signal; IO-Link; (configurable)
Electrical design PNP/NPN
Number of digital outputs 2
Output function normally open / closed; (configurable)
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 250
Short-circuit protection yes
Type of short-circuit protection yes (non-latching)
Overload protection yes
Measuring/setting range of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Measuring range
-100...600 °C -148...1112 °F
Set point SP
-99.8...600 °C -147.6...1112 °F
Reset point rP
-100...599.8 °C -148...1111.6 °F
In steps of
0.1 °C 0.1 °F
Resolution of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Resolution of switching output [K] 0.1
Resolution of display [K] 0.1
Accuracy / deviations of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Switch point accuracy [K] ± 0,3 + (± 0,1 % MS)
Display accuracy [K] ± 0,3 + (± 0,1 % MS)
Temperature coefficient [% of the span / 10 K] 0,1; (In case of deviation from the reference condition 25 ± 5 °C)
Reaction times of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Response time [ms] 390
Software / programming of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Parameter setting options hysteresis / window; normally open / closed; switching logic; switch-on/switch-off delay; Damping; Display unit
Interfaces of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Communication interface IO-Link
Transmission type COM2 (38,4 KBaud)
IO-Link revision 1.1
Operating conditions of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Ambient temperature [°C] -25...80
Storage temperature [°C] -40...100
Protection IP 67
Mechanical data of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Weight [g] 198
Material stainless steel (1.4404 / 316L); stainless steel (1.4301 / 304); PBT+PC-GF30; PBT-GF20; PC
Process connection threaded connection G 1/2 external thread
Displays / operating elements of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock
Display
Display unit 2 x LED, green
Switching status 2 x LED, yellow
Measured values alphanumeric display, red/green 4-digit

Ordering Models of IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

SI5000 PN2024 SI5002 PN7594 SI5010 PN5004 PN5004 PN3000 PN3001 PN3002 PN3006 PN5000 PN5001 PN5002 PN5003 PN5004 PN5006 PN7000 PN7001
PN7002 PN7003 PN7004 PN7006 PN7007 PN7009 SI5004 SI5007 SI5010 SI5000 SI5010 PN7001 PN7002 PN7003 PN7004 PN7006 PN7007 PN7092 PN7093 PN7094 PN7096 PN7000 PN5001 PN5002 PN5003 PN5004 PN5006 PN5007 PN5000

IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

PA3022 PA3023 PA3024 PA3026 PA3027 PA3029  PA3060 PA3220 PA3221 PB5227 PB5320 PB5322  PB5323 PB5324 PB5327 PB6000 PB6001 PB6002  PB6006 PB7020 PB7021 PB7022 SI5010 PB7023 PB7024  PB7026 PB7027 PC5020 PC5022 PC7020 PC7022  PC9532 PD3223 PD3224 PD7024 PD7026 PE3000  PE3001 PE3002 PE3003 PE3004 PE3006 PE3009  PE3020 PE3021 PE3022 PE3023 PE3024 PE3026  PE3027 PE3029 PE3220 PE3222 PE3223 PE3224  PE3226 PE5023 PE5024 PE5026 PE7002 PE7003  PE7004 PE7006 PE7009 PE7020 PE7021 PE7022 PE7023 PE7024 PE7026 PE7027 PH0504 PH0506  PH0507 PH0516 PH1214 PH1254 PH9956 PH9957 PH9958 PI2053 PI2054 PI2056 PI2057 PI2058  PI2063 PI2064 PI2066 PI2067 PI2092 PI2093 PI2094 PI2095 PI2096 PI2097 PI2098 PI2099  EC2050 EC2052 EC2053 EC2055 EC2056 EC2058 EC2059 EC2060

IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

SI5000 PN5003 PE7002 ID5005 PA3020 PA3023 PA9020 PA9021 PK7522 PN2021 PN2024 TN2531 TN7531 SI5000 SI5002 SI5007 SI5010 SI5000 SI5002 SI5010 PN5004 PN2022 PN2024 PN5004 PN2022 PN2597 PN3060 PN5006 PN5004 PN7003 PN7000 PN7002 PN7004 SI5002 SI5007 SI5010 EVC001 EVC004 PN7594 PG2409 PG2451 PG2452 PG2454 PG2456 PG2457 PG2789 PG2793 PG2794 PG2795 PG2796 PG2797 PG2798 PG2799 PG2889 PG2893 PG2894 PG2895 PG2896 PG2897 PG2898 PG2899 PG2450 PG2453 PG2455 PG2458 PG2459 PG2542 SI5000 SI5002 SI5007 SI5010 PN2022 PN2024 PN5004 SI5002 PN5004

PN2009 PN2020 PN2021 PN2022 PN2023 PN2024 PN2026 PN2027 PN2028 PN2060 PN2069 PN2070 PN2071 PN2092 PN2093 PN2094 PN2096 PN2097 PN2098 PN2099 PN2160 PN2169 PN2209 PN2220 PN2221 PN2222 PN2223 PN2224 PN2226 PN2227 PN2228 PN2270 PN2271 PN2292 PN2293 PN2294 PN2296 PN2297 PN2298 PN2299 PN2560 PN2569 PN2570 PN2571 PN2592 PN2593 PN2594 PN2596 PN2597 PN2598 PN2599 PN2670 PN2671 PN2692 PN2693 PN2694 PN2696 PN2697 PN2698 PN2699 PN3000

IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

SI5000 SI5002 SI5010 PN2022 PN2024 PN5004 PN5007 PN5004 SI5002 SI5000 PN5003 PE7002 PA3020 PA3021 PA3022 PA3023 PA3024 PA3026 PA3027 PA3028 PA3028 PA3029 PA3060 PA3220 PA3221 PA3222 PA3223 PA3224 PA9020 PA9021 PA9022 PA9023 PA9024 PA9026 PA9027 PA9028 PA9029 PA9060 PF2654 PF2657 PF2658 PI2203 PI2204 PI2205 PI2206 PI2207 PI2209 PI2303 PI2304 PI2305 PI2306 PI2307 PI2309 PI2789 PI2793 PI2794 PI2795 PI2796 PI2797 PI2798 PI2799 PI2889 PI2893 PI2894 PI2895 PI2896 PI2897 PI2898 PI2899 PK5520 PK5521 PK5522 PK5523 PK5524 PK6220 PK6222 PK6224 PK6520 PK6521 PK6522 PK6523 PK6524 PK7520 PK7521 PK7522 PK7523 PK7524 PL2654 PL2657 PL2658 PN2009 PN2020 PN2021 PN2024 PN2023 PN2026 PN2027 PN2028 PN2069 PN2070 PN2071 PN2092 PN2093 PN2094 PN2096 PN2097 PN2098 PN2099 PN2169 PN2209 PN2220 PN2221 PN2222 PN2223 PN2224 PN2226 PN2227
PN2228 PN2570 PN2571 PN2592 PN2593 PN2594 PN2596 PN2598 PN3000 PN3001 PN3002 PN3003 PN3004 PN3006 PN3007 PN3029 PN2022 PN5000 PN5001 PN5002 PN2597 PN3060 PN5006 PN5007 PN5200 PN5201 PN5202 PN5203 PN5204 PN5206 PN5207 PN7001 PN5004 PN7003 PN7000 PN7006 PN7007 PN7009 PN7060 PN7070 PN7071 PN7092 PN7093 PN7094 PN7096 PN7099 PN7570 PN7571 PN7592 PN7593 PN7002 PN7596 PN7599 PNI021 PNI022 PNI023 PNI023 PNI024 PNI024 PP2001 PP7550 PP7551 PP7552 PP7553 PP7554 PP7556 PQ0809 PQ0834 PQ3809 PQ3834 PQ7809 PQ7809 PQ7834 PQ7834 PS7570 PS7570

IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

PP7553 PN3007 PN7009 PP7554 PN3060 PN7060 PP7556 PN3070 PN7070 PN004A PN3071 PN7071 PN009A PN3092 PN7092 PN006A PN3093 PN7093 PN007A PN3094 PN7094 PN014A PN3097 PN7099 PN016A PN3096 PN7096 PN2009 PN3129 PN7097 PN2020 PN3160 PN7160 PN2021 PN3529 PN7270 PN2022 PN3560 PN7271 PN2023 PN3570 PN7292 PN2024 PN3571 PN7293 PN2026 PN3592 PN7294 PN2027 PN3593 PN7299 PN2028 PN3594 PN7296 PN2069 PN3597 PN7297 PN2070 PN3596 PN7270 PN2071 PN4220 PN7299 PN2092 PN4221 PN7370 PN2093 PN4222 PN7392 PN2094 PN4223 PN7560 PN2098 PN4224 PN7570 PN2099 PN4225 PN7571 PN2209 PN4226 PN7592 PN2220 PN4227 PN7593 PN2221 PN4229 PN7594 PN2222 PN5000 PN7599

IFM TR7439 Evaluation Unit for Temperature Sensor TR7439 TR-000KDBM12-QFPKG/US/ In Stock

330101-00-14-10-02-00 330101-00-08-10-02-05 330101-00-08-10-02-00 330101-00-30-05-02-00 330101-00-30-10-02-00 330102-00-12-10-02-00 330102-00-32-10-02-05 330102-00-16-10-02-05 330102-00-32-10-02-05 330103-00-22-05-02-00 330103-01-07-50-02-00 330103-00-06-10-02-05 330103-00-05-05-02-00 330104-00-02-10-02-00 330104-00-03-10-02-00 330104-00-04-10-02-00 330104-00-05-10-02-00
