Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules M

description:Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches...
BASIC INFO
Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches







Technical Specification of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches


Industrial Ethernet:
Modular Industrial Switches:Configurable Media Modules - MSM :Gigabit Ethernet MSM Media Modules, standard


Name Gigabit Ethernet MSM Media Modules, standard
Gigabit Ethernet media module for PowerMICE Switches (MSP).


Delivery informations of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Availability available
Product description
Description Gigabit Ethernet media module for PowerMICE Switches (MSP).
Port type and quantity Port 1: Gigabit Combo Port (10/100/1000Base-TX); Port 2: Gigabit Combo Port (10/100/1000Base-TX); Port 3: Gigabit Combo Port (10/100/1000Base-TX); Port
4: Gigabit Combo Port (10/100/1000Base-TX)
Type MSM40-C1C1C1C1SZ9HH9E99.9
Order No. MSM40-C1C1C1C1SZ9HH9E99.9

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Network size - length of cable
Twisted pair (TP) 0 m ... 100 m


Power requirements
Operating voltage Power supply via the backplane of the MICE switch


Ambient conditions of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Operating temperature 0 ºC ... 60 ºC
Storage/transport temperature -40 ºC ... 85 ºC
Protective paint on PCB No
Relative humidity (non-condensing) 5 % ... 95 %


Mechanical construction of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Dimensions (W x H x D) 38 mm x 134 mm x 118 mm
Mounting Backplane
Weight n/a
Protection class IP20


Mechanical stability
IEC 60068-2-27 shock 15 g, 11 ms duration, 18 shocks


Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

EMC interference immunity
EN 61000-4-2 electrostatic discharge (ESD) 4 kV contact discharge, 8 kV air discharge
EN 61000-4-3 electromagnetic field 10 V/m (80 - 1000 MHz)
EN 61000-4-4 fast transients (burst) 2 kV power line, 1 kV data line
EN 61000-4-5 surge voltage power line: 2 kV (line/earth), 1 kV (line/line), 1 kV data line
EN 61000-4-6 conducted immunity 10 V (150 kHz-80 MHz)


EMC emitted immunity
FCC CFR47 Part 15 FCC 47 CFR Part 15 Class A
EN 55022 EN 55022 Class A



Approvals of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Basis Standard CE, EN61131
Safety of information technology equipment EN 60950-1
Transportation NEMA TS2
Country Approval C-Tick


Scope of delivery and accessories
Scope of delivery Module, operating manual



Ordering Models of Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

943009102    MSP30-08040SCZ999HHE2A
943010001    MSM40-C1C1C1C1SZ9HH9E
943722101    MSM40-T1T1T1T1SZ9HH9E
943009102    MSP30-16040SCZ999HHE2A
943010001    MSM40-C1C1C1C1SZ9HH9E
943722101    MSM40-T1T1T1T1SZ9HH9E
943009102    MSP30-24040SCZ999HHE2A
943010001    MSM40-C1C1C1C1SZ9HH9E
943722101    MSM40-T1T1T1T1SZ9HH9E

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

HIRSCHMANN    MSP40-C1C1C1C1TZ9HH9E99.9
HIRSCHMANN    MSP30-24040TCZ9MRHHE3AXX.X
HIRSCHMANN    M-SFP-LX/LC EEC 943897-001
HIRSCHMANN    ACA 31 942074-001
HIRSCHMANN    MSM40-T1T1T1T1TZ9HH9E99.9
HIRSCHMANN    MSM20-M2M2M2M2TZ9HH9E99.
HIRSCHMANN    MSP30-24040SCY9URHHE2AXX.X
HIRSCHMANN    MSM40-T1T1T1T1SY9HH9E99.9
HIRSCHMANN    MS20-1600SAAEHC
HIRSCHMANN    MSP30-16040SCZ999HHE2A

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

SPIDER-PL-20-01T1M29999TY9HHHH
SPIDER-PL-20-04T1M29999TZ9HHHH
SPIDER-PL-20-08T1999999TWVHHHH
SPIDER-SL-20-05T1999999SY9HHHH
SPIDER-SL-20-05T1999999TY9HHHH
SPIDER-SL-20-08T1999999SY9HHHH
SPIDER-SL-20-08T1999999TY9HHHH
SPIDER-SL-40-05T1999999SY9HHHH
SPIDER-SL-40-08T1999999SY9HHHH
SPIDER-SL-20-01T1M29999SY9HHHH
SPIDER-SL-20-01T1S29999SY9HHHH
SPIDER-SL-20-04T1M29999SY9HHHH
SPIDER-SL-20-04T1M29999TY9HHHH
SPIDER-SL-20-04T1M49999SY9HHHH
SPIDER-SL-20-04T1M49999TY9HHHH
SPIDER-SL-20-04T1S29999SY9HHHH
SPIDER-SL-20-06T1M29999SY9HHHH
SPIDER-SL-20-06T1S29999SY9HHHH
SPIDER-SL-20-06T1M2M299SY9HHHH
SPIDER-SL-20-06T1S2S299SY9HHHH
SPIDER-SL-40-06T1O69999SY9HHHH
SPIDER-SL-40-06T1O6O699SY9HHHH
SPIDER-PL-20-05T1999999TY9HHHH
SPIDER-PL-20-08T1999999TY9HHHH
SPIDER-PL-20-16T1999999TZ9HHHV
SPIDER-PL-40-05T1999999TY9HHHH
SPIDER-PL-40-08T1999999TY9HHHH
SPIDER-PL-20-01T1M29999TY9HHHH
SPIDER-PL-20-01T1S29999TY9HHHH
SPIDER-PL-20-04T1M29999TY9HHHH
SPIDER-PL-20-04T1M49999TY9HHHH
SPIDER-PL-20-04T1S29999TY9HHHH
SPIDER-PL-20-06T1Z6Z6Z6TY9HHHH
SPIDER-PL-20-08T1M29999TY9HHHH
SPIDER-PL-20-08T1S29999TY9HHHH
SPIDER-PL-20-07T1M2M299TY9HHHH
SPIDER-PL-20-07T1S2S299TY9HHHH
SPIDER-PL-20-24T1Z6Z699TZ9HHHV
SPIDER-PL-40-01T1O69999TY9HHHH
SPIDER-PL-40-04T1O69999TY9HHHH
SPIDER-PL-20-07T1M2M299TWVHHHH
SPIDER-PL-20-07T1S2S299TWVHHHH
SPIDER-PL-20-05T1999999TWVHHHH
SPIDER-PL-20-04T1M29999TWVHHHH
SPIDER-PL-20-04T1S29999TWVHHHH
SPIDER-PL-20-04T1M49999TWVHHHH
SPIDER-PL-20-05T1999999TWVHHHH
SPIDER-PL-20-04T1M29999TWVHHHH
SPIDER-PL-20-08T1999999TWVHHHH
SPIDER-SL-20-05T1999999SZ9HHHH
SPIDER-SL-20-05T1999999TZ9HHHH
SPIDER-SL-20-08T1999999SZ9HHHH
SPIDER-SL-20-08T1999999TZ9HHHH
SPIDER-SL-40-05T1999999SZ9HHHH
SPIDER-SL-40-08T1999999SZ9HHHH
SPIDER-SL-20-01T1M29999SZ9HHHH
SPIDER-SL-20-01T1S29999SZ9HHHH
SPIDER-SL-20-04T1M29999SZ9HHHH
SPIDER-SL-20-04T1M29999TZ9HHHH
SPIDER-SL-20-04T1M49999SZ9HHHH
SPIDER-SL-20-04T1M49999TZ9HHHH
SPIDER-SL-20-04T1S29999SZ9HHHH
SPIDER-SL-20-06T1M29999SZ9HHHH
SPIDER-SL-20-06T1S29999SZ9HHHH


Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

942132001 SPIDER-SL-20-05T1999999SZ9HHHH 5 x 10/100Base-TX
942132016 SPIDER-SL-20-05T1999999TZ9HHHH 5 x 10/100Base-TX
942132002 SPIDER-SL-20-08T1999999SZ9HHHH 8 x 10/100Base-TX
942132017 SPIDER-SL-20-08T1999999TZ9HHHH 8 x 10/100Base-TX
942132003 SPIDER-SL-40-05T1999999SZ9HHHH 5 x 10/100/1000Base-T
942132004 SPIDER-SL-40-08T1999999SZ9HHHH 8 x 10/100/1000Base-T
942132005 SPIDER-SL-20-01T1M29999SZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132006 SPIDER-SL-20-01T1S29999SZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132007 SPIDER-SL-20-04T1M29999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132018 SPIDER-SL-20-04T1M29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132008 SPIDER-SL-20-04T1M49999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942132019 SPIDER-SL-20-04T1M49999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942132009 SPIDER-SL-20-04T1S29999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132010 SPIDER-SL-20-06T1M29999SZ9HHHH 6 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132011 SPIDER-SL-20-06T1S29999SZ9HHHH 6 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132012 SPIDER-SL-20-06T1M2M299SZ9HHHH 6 x 10/100Base-TX, 2 x 100Base-FX, MM, SC connector
942132013 SPIDER-SL-20-06T1S2S299SZ9HHHH 6 x 10/100Base-TX, 2 x 100Base-FX, SM, SC connector
942132014 SPIDER-SL-40-06T1O69999SZ9HHHH 6 x 10/100/1000Base-T, 1 x FE/GE SFP slot
942132015 SPIDER-SL-40-06T1O6O699SZ9HHHH 6 x 10/100/1000Base-T, 2 x FE/GE SFP slot

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

942141016 SPIDER-PL-20-05T1999999TZ9HHHH 5 x 10/100Base-TX
942141017 SPIDER-PL-20-08T1999999TZ9HHHH 8 x 10/100Base-TX
942141019 SPIDER-PL-40-05T1999999TZ9HHHH 5 x 10/100/1000Base-T
942141020 SPIDER-PL-40-08T1999999TZ9HHHH 8 x 10/100/1000Base-T
942141022 SPIDER-PL-20-01T1M29999TZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141023 SPIDER-PL-20-01T1S29999TZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141024 SPIDER-PL-20-04T1M29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141025 SPIDER-PL-20-04T1M49999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942141026 SPIDER-PL-20-04T1S29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141027 SPIDER-PL-20-06T1Z6Z6Z6TZ9HHHH 6 x 10/100Base-TX, 3 x FE SFP slot
942141028 SPIDER-PL-20-08T1M29999TZ9HHHH 8 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141029 SPIDER-PL-20-08T1S29999TZ9HHHH 8 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141030 SPIDER-PL-20-07T1M2M299TZ9HHHH 7 x 10/100Base-TX, 2 x 100Base-FX, MM, SC connector
942141031 SPIDER-PL-20-07T1S2S299TZ9HHHH 7 x 10/100Base-TX, 2 x 100Base-FX, SM, SC connector
942141033 SPIDER-PL-40-01T1O69999TZ9HHHH 1 x 10/100/1000Base-T, 1 x FE/GE SFP slot
942141034 SPIDER-PL-40-04T1O69999TZ9HHHH 4 x 10/100/1000Base-T, 1 x FE/GE SFP slot

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

943 771-001 RS2-3TX/2FX EEC SPIDER-PL-20-07T1M2M299TWVHHHH
943 772-001 RS2-3TX/2FX-SM EEC SPIDER-PL-20-07T1S2S299TWVHHHH
943 819-001 RS2-4TX EEC SPIDER-PL-20-05T1999999TWVHHHH
943 773-001 RS2-4TX/1FX EEC SPIDER-PL-20-04T1M29999TWVHHHH
943 774-001 RS2-4TX/1FX-SM EEC SPIDER-PL-20-04T1S29999TWVHHHH
943 119-002 RS2-4TX/1FX-ST EEC SPIDER-PL-20-04T1M49999TWVHHHH
943 732-003 RS2-5TX SPIDER-PL-20-05T1999999TWVHHHH
943 732-103 RS2-5TX/FX SPIDER-PL-20-04T1M29999TWVHHHH

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches


942132001 SPIDER-SL-20-05T1999999SZ9HHHH 5 x 10/100Base-TX
942132016 SPIDER-SL-20-05T1999999TZ9HHHH 5 x 10/100Base-TX
942132002 SPIDER-SL-20-08T1999999SZ9HHHH 8 x 10/100Base-TX
942132017 SPIDER-SL-20-08T1999999TZ9HHHH 8 x 10/100Base-TX
942132003 SPIDER-SL-40-05T1999999SZ9HHHH 5 x 10/100/1000Base-T
942132004 SPIDER-SL-40-08T1999999SZ9HHHH 8 x 10/100/1000Base-T
942132005 SPIDER-SL-20-01T1M29999SZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132006 SPIDER-SL-20-01T1S29999SZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132007 SPIDER-SL-20-04T1M29999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132018 SPIDER-SL-20-04T1M29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132008 SPIDER-SL-20-04T1M49999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942132019 SPIDER-SL-20-04T1M49999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942132009 SPIDER-SL-20-04T1S29999SZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132010 SPIDER-SL-20-06T1M29999SZ9HHHH 6 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942132011 SPIDER-SL-20-06T1S29999SZ9HHHH 6 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942132012 SPIDER-SL-20-06T1M2M299SZ9HHHH 6 x 10/100Base-TX, 2 x 100Base-FX, MM, SC connector
942132013 SPIDER-SL-20-06T1S2S299SZ9HHHH 6 x 10/100Base-TX, 2 x 100Base-FX, SM, SC connector
942132014 SPIDER-SL-40-06T1O69999SZ9HHHH 6 x 10/100/1000Base-T, 1 x FE/GE SFP slot
942132015 SPIDER-SL-40-06T1O6O699SZ9HHHH 6 x 10/100/1000Base-T, 2 x FE/GE SFP slot

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

942141016 SPIDER-PL-20-05T1999999TZ9HHHH 5 x 10/100Base-TX
942141017 SPIDER-PL-20-08T1999999TZ9HHHH 8 x 10/100Base-TX
942141019 SPIDER-PL-40-05T1999999TZ9HHHH 5 x 10/100/1000Base-T
942141020 SPIDER-PL-40-08T1999999TZ9HHHH 8 x 10/100/1000Base-T
942141022 SPIDER-PL-20-01T1M29999TZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141023 SPIDER-PL-20-01T1S29999TZ9HHHH 1 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141024 SPIDER-PL-20-04T1M29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141025 SPIDER-PL-20-04T1M49999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, MM, ST connector
942141026 SPIDER-PL-20-04T1S29999TZ9HHHH 4 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141027 SPIDER-PL-20-06T1Z6Z6Z6TZ9HHHH 6 x 10/100Base-TX, 3 x FE SFP slot
942141028 SPIDER-PL-20-08T1M29999TZ9HHHH 8 x 10/100Base-TX, 1 x 100Base-FX, MM, SC connector
942141029 SPIDER-PL-20-08T1S29999TZ9HHHH 8 x 10/100Base-TX, 1 x 100Base-FX, SM, SC connector
942141030 SPIDER-PL-20-07T1M2M299TZ9HHHH 7 x 10/100Base-TX, 2 x 100Base-FX, MM, SC connector
942141031 SPIDER-PL-20-07T1S2S299TZ9HHHH 7 x 10/100Base-TX, 2 x 100Base-FX, SM, SC connector
942141033 SPIDER-PL-40-01T1O69999TZ9HHHH 1 x 10/100/1000Base-T, 1 x FE/GE SFP slot
942141034 SPIDER-PL-40-04T1O69999TZ9HHHH 4 x 10/100/1000Base-T, 1 x FE/GE SFP slot

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

SPIDER 1TX/1FX
SPIDER 1TX/1FX-SM
SPIDER 1TX/1FX EEC
SPIDER 1TX/1FX-SM EEC
SPIDER 3TX-TAP
SPIDER 4TX/1FX-ST EEC
SPIDER 4TX/1FX
SPIDER 4TX/1FX-SM EEC
SPIDER 4TX/1FX EEC
SPIDER 5TX
SPIDER 5TX EEC
SPIDER II 8TX
SPIDER II  8TX EEC
SPIDER II Giga 5T EEC
SPIDER II Giga 5T EEC Jumbo
SPIDER II Giga 5T EEC Pro
SPIDER II Giga 5T/2S EEC
SPIDER II Giga 5T/2S EEC Jumbo
SPIDER II Giga 5T/2S EEC Pro
SPIDER II 8TX/1FX-ST EEC
SPIDER II 8TX/2FX-SM EEC
SPIDER II 8TX/2FX-ST EEC
SPIDER II 8TX/1FX-SM EEC
SPIDER II 8TX/1FX EEC
SPIDER II 8TX/2FX EEC
SPIDER II 8TX
SPIDER II 8TX EEC
SPIDER II 16TX EEC
SPIDER II 16TX/2DS-S EEC942049001 EES, Evalboard


Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

943890001 SPIDER 1TX/1FX
943891001 SPIDER 1TX/1FX-SM
943927001 SPIDER 1TX/1FX EEC
943928001 SPIDER 1TX/1FX-SM EEC
943899001 SPIDER 3TX-TAP
943221001 SPIDER 4TX/1FX
943221101 SPIDER 4TX/1FX EEC
943880001 SPIDER 4TX/1FX-SM EEC
943914001 SPIDER 4TX/1FX-ST EEC
943824002 SPIDER 5TX
943824102 SPIDER 5TX EEC
943376001 SPIDER 8TX
943376201 SPIDER 8TX EEC
943957001 SPIDER II 8TX
943958001 SPIDER II 8TX EEC
943958111 SPIDER II 8TX/1FX EEC
943958131 SPIDER II 8TX/1FX-SM EEC
943958121 SPIDER II 8TX/1FX-ST EEC
943958211 SPIDER II 8TX/2FX EEC
943958231 SPIDER II 8TX/2FX-SM EEC
943958221 SPIDER II 8TX/2FX-ST EEC
943962002 SPIDER II Giga 5T EEC
943963002 SPIDER II Giga 5T/2S EEC
942008001 SPIDER II 8TX PoE

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

942014001 RSB20-0800T1T1SAABHH
942014002 RSB20-0800M2M2SAABHH
942014003 RSB20-0800S2S2SAABHH
942014033 RSB20-0800S4S4SAABHH
942014004 RSB20-0900ZZZ6SAABHH
942014005 RSB20-0900M2TTSAABHH
942014006 RSB20-0900S2TTSAABHH
942014007 RSB20-0900MMM2SAABHH
942014008 RSB20-0900VVM2SAABHH
942014009 RSB20-0800T1T1TAABHH
942014010 RSB20-0800M2M2TAABHH
942014011 RSB20-0800S2S2TAABHH
942014034 RSB20-0800S4S4TAABHH
942014012 RSB20-0900ZZZ6TAABHH
942014013 RSB20-0900M2TTTAABHH
942014014 RSB20-0900S2TTTAABHH
942014015 RSB20-0900MMM2TAABHH
942014016 RSB20-0900VVM2TAABHH

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

943733102 MB-2T
943938999 MM20-P9P9T1T1SZHC
943718101 MM2-2FXM2
943719101 MM2-2FXS2
943720101 MM2-2FXM3/2TX1
943721101 MM2-4FXM3
943722101 MM2-4TX1
943722151 MM2-4TX1-EEC
943955001 MM3-4TX1-RT EEC
943955002 MM3-2FXM2/2TX1-RT EEC
943955003 MM3-2FXS2/2TX1-RT EEC
943760101 MM3-4FLM4
943761101 MM3-2FXM2/2TX1
943761151 MM3-2FXM2/2TX1-EEC
943762101 MM3-2FXS2/2TX1
943762151 MM3-2FXS2/2TX1-EEC
943763101 MM3-1FXL2/3TX1
943764101 MM3-4FXM2
943835101 MM3-4FXM4
943836101 MM3-4FXS2
943837101 MM3-2FXM4/2TX1
943838101 MM3-1FXS2/3TX1
943838151 MM3-1FXS2/3TX1-EEC
943839101 MM3-1FXM2/3TX1
943938999 MM20-A8A89999SAHH
943841101 MM3-4TX5
943938999 MM20-P9P9P9P9SZHC
943929101 MM3-1FXS2/1FXM2/2TX1
943010001 MM4-4TX/SFP
943622001 MM4-2TX/SFP
943938002 MM22-T1T1T1T1SAHH
943938999 MM20-M2M2M2M2TAHH
943939999 MB20-2TAHH
943938001 MM20-Z6Z6Z6Z6SAHH
943938999 MM20-Z6Z6Z6Z6TAHH
943938999 MM20-Z6Z6Z6Z6EAHH
943938999 MM20-T1T1T1T1TAHH
943938999 MM30-O7O79999TAHH
943938999 MM30-O7O7O7O7TAHH
943938999 MM20-L2L2L2L2TAHH
943938999 MM23-T1T1T1T1SAHH
943938999 MM23-M2M2T1T1SAHH
943938999 MM23-S2S2T1T1SAHH
943938999 MM23-F4F4T1T1SAHH
943938999 MM33-O7O79999SAHH

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

943969401 MACH102-24TP-F
943969501 MACH102-24TP-FR
943969001 MACH102-8TP
943969201 MACH102-8TP-F
943969301 MACH102-8TP-FR
943969101 MACH102-8TP-R
942003001 MACH104-20TX-F
942003101 MACH104-20TX-FR
942003201 MACH104-20TX-F-4PoE
942030001 MACH104-16TX-PoEP
942026001 MACH104-16TX-PoEP-R
942027001 MACH104-16TX-PoEP-E
942031001 MACH104-16TX-PoEP+2X
942033001 MACH104-16TX-PoEP+2X-R
942032001 MACH104-16TX-PoEP+2X-E
943970101 M1-8MM-SC
943970301 M1-8SFP
943970201 M1-8SM-SC
943970001 M1-8TP-RJ45
942028001 M1-8TP-RJ45 PoE
943916101 MACH4002-24G-L2PHC
943916201 MACH4002-24G-L3EHC
943916301 MACH4002-24G-L3PHC
943911101 MACH4002-48G-L2PHC
943911201 MACH4002-48G-L3EHC
943911301 MACH4002-48G-L3PHC
943915101 MACH4002-24G+3X-L2PHC
943915201 MACH4002-24G+3X-L3EHC
943915301 MACH4002-24G+3X-L3PHC
943878101 MACH4002-48G+3X-L2PHC
943878201 MACH4002-48G+3X-L3EHC
943878301 MACH4002-48G+3X-L3PHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

Part No. Order No. Ports/Features
RS20-0900VVM2TDAU 943 434-060 3 x 100 Mbit/s SM SC and 6 x 10/100 Mbit/s RJ45
RS20-1600S2T1SDAU 943 434-051 1 x 100 Mbit/s SM SC and 15 x 10/100 Mbit/s RJ45
RS20-1600S2S2SDAU 943 434-053 2 x 100 Mbit/s SM SC and 14 x 10/100 Mbit/s RJ45
RS20-1600L2T1SDAU 943 434-054 1 x 100 Mbit/s Long Haul SM SC and 15 x 10/100 Mbit/s RJ45
RS20-1600L2S2SDAU 943 434-056 1 x 100 Mbit/s Long Haul SM SC,1 x 100 Mbit/s SM SC and 14 x 10/100 Mbit/s RJ45
RS20-1600L2L2SDAU 943 434-057 2 x 100 Mbit/s Long Haul SM SC and 14 x 10/100 Mbit/s RJ45
RS20-1600S2M2SDAU 943 434-052 1 x 100 Mbit/s MM SC,1 x 100 Mbit/s SM SC and 14 x 10/100 Mbit/s RJ45
RS20-1600L2M2SDAU 943 434-055 1 x 100 Mbit/s MM SC, 1 x 100 Mbit/s Long Haul SM SC and 14 x 10/100 Mbit/s RJ45


Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS20-0400T1T1SDAEHC
RS20-0400M2M2SDAEHC
RS20-0400S2S2SDAEHC
RS20-0400T1T1SDBEHC
RS20-0400M2M2SDBEHC
RS20-0400S2S2SDBEHC
RS20-0400T1T1SDAPHC
RS20-0400M2M2SDAPHC
RS20-0400S2S2SDAPHC
RS20-0400T1T1SDBPHC
RS20-0400M2M2SDBPHC
RS20-0400S2S2SDBPHC
RS20-0400T1T1SDABHC
RS20-0400M2M2SDABHC
RS20-0400T1T1SDBBHC
RS20-0400M2M2SDBBHC
RS20-1600T1T1SDAEHC
RS20-1600M2M2SDAEHC
RS20-1600S2S2SDAEHC
RS20-1600T1T1SDBEHC
RS20-1600M2M2SDBEHC
RS20-1600S2S2SDBEHC
RS20-1600T1T1SDAPHC
RS20-1600M2M2SDAPHC
RS20-1600S2S2SDAPHC
RS20-1600T1T1SDBPHC
RS20-1600M2M2SDBPHC
RS20-1600S2S2SDBPHC
RS20-1600T1T1SDAUHC
RS20-1600M2M2SDAUHC
RS20-1600S2S2SDAUHC
RS20-1600T1T1SDBUHC
RS20-1600M2M2SDBUHC
RS20-1600S2S2SDBUHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS30-1602T1T1SDAEHC
RS30-1602O6O6SDAEHC
RS30-1602T1T1SDBEHC
RS30-1602O6O6SDBEHC
RS30-1602T1T1SDAPHC
RS30-1602O6O6SDAPHC
RS30-1602T1T1SDBPHC
RS30-1602O6O6SDBPHC
RS30-1602T1T1SDAUHC
RS30-1602O6O6SDAUHC
RS30-1602T1T1SDBUHC
RS30-1602O6O6SDBUHC
RS30-2402T1T1SDAPHC
RS30-2402O6O6SDAPHC
RS30-2402T1T1SDBPHC
RS30-2402O6O6SDBPHC
RS30-2402T1T1SDAUHC
RS30-2402O6O6SDAUHC
RS30-2402T1T1SDBUHC
RS30-2402O6O6SDBUHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS20-0800T1T1SDAEHC
RS20-0800M2M2SDAEHC
RS20-0800S2S2SDAEHC
RS20-0800T1T1SDBEHC
RS20-0800M2M2SDBEHC
RS20-0800S2S2SDBEHC
RS20-0800T1T1SDAPHC
RS20-0800M2M2SDAPHC
RS20-0800S2S2SDAPHC
RS20-0800T1T1SDBPHC
RS20-0800M2M2SDBPHC
RS20-0800S2S2SDBPHC
RS20-0800T1T1SDAUHC
RS20-0800M2M2SDAUHC
RS20-0800S2S2SDAUHC
RS20-0800T1T1SDBUHC
RS20-0800M2M2SDBUHC
RS20-0800S2S2SDBUHC
RS20-0800T1T1SDABHC
RS20-0800M2M2SDABHC
RS20-0800T1T1SDBBHC
RS20-0800M2M2SDBBHC
RS20-2400T1T1SDAEHC
RS20-2400M2M2SDAEHC
RS20-2400S2S2SDAEHC
RS20-2400T1T1SDBEHC
RS20-2400M2M2SDBEHC
RS20-2400S2S2SDBEHC
RS20-2400T1T1SDAPHC
RS20-2400M2M2SDAPHC
RS20-2400S2S2SDAPHC
RS20-2400T1T1SDBPHC
RS20-2400M2M2SDBPHC
RS20-2400S2S2SDBPHC
RS20-2400T1T1SDAUHC
RS20-2400M2M2SDAUHC
RS20-2400S2S2SDAUHC
RS20-2400T1T1SDBUHC
RS20-2400M2M2SDBUHC
RS20-2400S2S2SDBUHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS30-0802T1T1SDAEHC
RS30-0802O6O6SDAEHC
RS30-0802T1T1SDBEHC
RS30-0802O6O6SDBEHC
RS30-0802T1T1SDAPHC
RS30-0802O6O6SDAPHC
RS30-0802T1T1SDBPHC
RS30-0802O6O6SDBPHC
RS30-0802T1T1SDAUHC
RS30-0802O6O6SDAUHC
RS30-0802T1T1SDBUHC
RS30-0802O6O6SDBUHC
RS30-2402T1T1SDAEHC
RS30-2402O6O6SDAEHC
RS30-2402T1T1SDBEHC
RS30-2402O6O6SDBEHC
RS30-0802OOZZSDAEHC
RS30-0802OOZZSDAPHC
RS30-0802OOZZSDAUHC
RS30-0802OOZZSDHEHC
RS30-0802OOZZSDHPHC
RS30-0802OOZZSDHUHC
RS30-0802OOZZSDBEHC
RS30-0802OOZZSDBPHC
RS30-0802OOZZSDBUHC
RS30-0802OOZZTDAEHC
RS30-0802OOZZTDAPHC
RS30-0802OOZZTDAUHC
RS30-0802OOZZTDHEHC
RS30-0802OOZZTDHPHC
RS30-0802OOZZTDHUHC
RS30-0802OOZZTDBEHC
RS30-0802OOZZTDBPHC
RS30-0802OOZZTDBUHC
RS30-0802OOZZEDAEHC
RS30-0802OOZZEDAPHC
RS30-0802OOZZEDAUHC
RS30-0802OOZZEDHEHC
RS30-0802OOZZEDHPHC
RS30-0802OOZZEDHUHC
RS30-0802OOZZEDBEHC
RS30-0802OOZZEDBPHC
RS30-0802OOZZEDBUHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS30-2402OOZZSDAEHC
RS30-2402OOZZSDAPHC
RS30-2402OOZZSDAUHC
RS30-2402OOZZSDHEHC
RS30-2402OOZZSDHPHC
RS30-2402OOZZSDHUHC
RS30-2402OOZZSDBEHC
RS30-2402OOZZSDBPHC
RS30-2402OOZZSDBUHC

Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

RS30-1602OOZZSDAEHC
RS30-1602OOZZSDAPHC
RS30-1602OOZZSDAUHC
RS30-1602OOZZSDHEHC
RS30-1602OOZZSDHPHC
RS30-1602OOZZSDHUHC
RS30-1602OOZZSDBEHC
RS30-1602OOZZSDBPHC
RS30-1602OOZZSDBUHC
RS30-1602OOZZTDAEHC
RS30-1602OOZZTDAPHC
RS30-1602OOZZTDAUHC
RS30-1602OOZZTDHEHC
RS30-1602OOZZTDHPHC
RS30-1602OOZZTDHUHC
RS30-1602OOZZTDBEHC
RS30-1602OOZZTDBPHC
RS30-1602OOZZTDBUHC
RS30-1602OOZZEDAEHC
RS30-1602OOZZEDAPHC
RS30-1602OOZZEDAUHC
RS30-1602OOZZEDHEHC
RS30-1602OOZZEDHPHC
RS30-1602OOZZEDHUHC
RS30-1602OOZZEDBEHC
RS30-1602OOZZEDBPHC
RS30-1602OOZZEDBUHC


Hirschmann MSM40-C1C1C1C1SZ9HH9E MICE Switch Media Modules MSM20 MSM40 Industrial Rail Switches

We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.


We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.



Contact:
HONGKONG XIEYUAN TECH CO., LIMITED
Email:becky@hkxytech.com   Web:www.hkxytech.com
Mobile:+86-15972186287(Whatsapp & Wechat)

Previous:Hirshcmann MACH102-24TP-FR Gigabit Ethernet Switches MACH102 Next:
 Footer begin -->
