Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart

description:Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart ...
BASIC INFO

Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart





ATS22C41Q product specification as below for your reference.

Characteristics of Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart

Main
range of product
Altistart 22

product or component type
Soft starter

product destination
Asynchronous motors

product specific application
Pumps and fans

component name
ATS22

network number of phases
3 phases

[Us] rated supply voltage
230...440 V - 15...10 %

motor power kW
110 kW 230 V
220 kW 400 V
220 kW 440 V

factory setting current
388 A

power dissipation in W
177 W for standard applications

utilisation category
AC-53A

type of start
Start with torque control (current limited to 3.5 In)

IcL starter rating
410 A connection in the motor supply line for standard applications

IP degree of protection
IP00

Complementary of Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart

assembly style
With heat sink

function available
Internal bypass

supply voltage limits
195...484 V

supply frequency
50...60 Hz - 10...10 %

network frequency
45...66 Hz

device connection
To the motor delta terminals
In the motor supply line

[Uc] control circuit voltage
230 V -15...10 % 50/60 Hz

control circuit consumption
20 W

discrete output number
2

discrete output type
Relay outputs R1 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O
Relay outputs R2 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O

minimum switching current
100 mA 12 V DC relay outputs

maximum switching current
5 A 250 V AC resistive 1 relay outputs
5 A 30 V DC resistive 1 relay outputs
2 A 250 V AC inductive 0.4 20 ms relay outputs
2 A 30 V DC inductive 7 ms relay outputs

discrete input number
3

discrete input type
Logic LI1, LI2, LI3 5 mA 4.3 kOhm

discrete input voltage
24 V <= 30 V

discrete input logic
Positive logic LI1, LI2, LI3 < 5 V and <= 2 mA > 11 V >= 5 mA

output current
0.4...1 Icl adjustable

PTC probe input
750 Ohm

communication port protocol
Modbus

connector type
1 RJ45

communication data link
Serial

physical interface
RS485 multidrop

transmission rate
4800, 9600 or 19200 bps

installed device
31

protection type
Phase failure line
Thermal protection starter
Thermal protection motor

marking
CE

type of cooling
Forced convection

operating position
Vertical +/- 10 degree

height
425 mm

width
206 mm

depth
299 mm

product weight
33 kg

power range
110...220 kW at 380...440 V 3 phases
110...220 kW at 200...240 V 3 phases

motor starter type
Soft starter

Environment of Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart

electromagnetic compatibility
Conducted and radiated emissions level A IEC 60947-4-2
Damped oscillating waves level 3 IEC 61000-4-12
Electrostatic discharge level 3 IEC 61000-4-2
Immunity to electrical transients level 4 IEC 61000-4-4
Immunity to radiated radio-electrical interference level 3 IEC 61000-4-3
Voltage/current impulse level 3 IEC 61000-4-5

standards
EN/IEC 60947-4-2

product certifications
GOST
C-Tick
CSA
UL
CCC

vibration resistance
1.5 mm 2...13 Hz EN/IEC 60068-2-6
1 gn 13...200 Hz EN/IEC 60068-2-6

shock resistance
15 gn 11 ms EN/IEC 60068-2-27

noise level
56 dB

pollution degree
Level 2 IEC 60664-1

relative humidity
0...95 % without condensation or dripping water EN/IEC 60068-2-3

ambient air temperature for operation
-10...40 °C without derating
> 40...< 60 °C with current derating 2.2 % per °C

ambient air temperature for storage
-25...70 °C

operating altitude
<= 1000 m without derating
> 1000...< 2000 m with current derating of 2.2 % per additional 100 m


Ordering Models: Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart



ATS22D17Q ATS22 17 ATS22,17A,440V,220V
ATS22D32Q ATS22 32 ATS22,32A,440V,220V
ATS22D47Q ATS22 47 ATS22,47A,440V,220V
ATS22D62Q ATS22 62 ATS22,62A,440V,220V
ATS22D75Q ATS22 75 ATS22,75A,440V,220V
ATS22D88Q ATS22 88 ATS22,88A,440V,220V
ATS22C11Q ATS22 110 ATS22,110A,440V,220V
ATS22C14Q ATS22 140 ATS22,140A,440V,220V
ATS22C17Q ATS22 170 ATS22,170A,440V,220V
ATS22C21Q ATS22 210 ATS22,210A,440V,220V
ATS22C21S6 ATS22 210 ATS22,210A,600V,220V
ATS22C25S6 ATS22 250 ATS22,250A,600V,220V
ATS22C32S6 ATS22 320 ATS22,320A,600V,220V
ATS22C41S6 ATS22 410 ATS22,410A,600V,220V
ATS22C48S6 ATS22 480 ATS22,480A,600V,220V
ATS22C59S6 ATS22 590 ATS22,590A,600V,220V
ATS22D17S6U ATS22 17 ATS22,17A,600V,110V
ATS22D32S6U ATS22 32 ATS22,32A,600V,110V
ATS22D47S6U ATS22 47 ATS22,47A,600V,110V
ATS22D62S6U ATS22 62 ATS22,62A,600V,110V
ATS22D75S6U ATS22 75 ATS22,75A,600V,110V



Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart


ATS22C14Q ATS22C21Q ATS22C25Q ATS22C32Q ATS22C41Q ATS22C48Q ATS22C59Q ATS22C11S6
ATS22C17S6 ATS22C17S6U ATS22C32S6U ATS22C41S6U ATS22C48S6U ATS22C59S6U ATS22C25S6U
ATS22D17Q ATS22D32Q ATS22D47Q ATS22D62Q ATS22D75Q ATS22D88Q ATS22C11Q ATS22C17Q
ATS22C14Q ATS22C21Q ATS22C25Q ATS22C32Q ATS22C41Q ATS22C48Q ATS22C59Q ATS22C11S6
ATS22C17S6 ATS22C17S6U ATS22C32S6U ATS22C41S6U ATS22C48S6U ATS22C59S6U ATS22C25S6U
ATS22C14S6 ATS22C21S6 ATS22C25S6 ATS22C32S6 ATS22C41S6 ATS22C48S6 ATS22C11S6U
ATS22D17Q ATS22C59S6 ATS22C14S6U ATS22C21S6U ATS22D62S6U ATS22D75S6U ATS22D88S6U
ATS22C32Q ATS22C41Q ATS22C48Q ATS22C59Q ATS22D17S6U ATS22D32S6U ATS22D47S6U



Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart

ATS48D17Q ATS48 17 A 230~415V
ATS48D22Q ATS48 22 A 230~415V
ATS48D32Q ATS48 32 A 230~415V
ATS48D38Q ATS48 38 A 230~415V
ATS48D47Q ATS48 47 A 230~415V
ATS48D62Q ATS48 62 A 230~415V
ATS48D75Q ATS48 75 A 230~415V
ATS48D88Q ATS48 88 A 230~415V
ATS48C11Q ATS48 110A 230~415V
ATS48C14Q ATS48 140A 230~415V
ATS48C17Q ATS48 170A 230~415V
ATS48C21Q ATS48 210A 230~415V
ATS48C25Q ATS48 250A 230~415V
ATS48C32Q ATS48 320A 230~415V
ATS48C41Q ATS48 410A 230~415V
ATS48C48Q ATS48 480A 230~415V
ATS48C59Q ATS48 590A 230~415V
ATS48C66Q ATS48 660A 230~415V
ATS48C79Q ATS48 790A 230~415V
ATS48M10Q ATS48 1000A 230~415V
ATS48M12Q ATS48 1200A 230~415V


Schneider ATS22C41Q Soft Starters ATS22C41Q Altistart
