Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Sup

Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived






Features of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES
1-channel isolated barrier
24 V DC supply (Power Rail)
Input for 2-wire SMART transmitters and current sources
Signal splitter (1 input and 2 outputs)
Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V
Terminal blocks with test sockets
Up to SIL 3 acc. to IEC 61508




Technical data of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

General specifications of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Signal type Analog input


Functional safety related parameters of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Safety Integrity Level (SIL) SIL 3
Systematic capability (SC) SC 3


Supply of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Connection Power Rail or terminals 9+, 10-
Rated voltage 18 ... 30 V DC
Ripple within the supply tolerance
Power dissipation approx. 1.4 W at 20 mA transfer current, 250 Ω in both outputs
Power consumption 2 W


Input of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Connection side field side
Connection terminals 1+, 2- (sink); 3+, 4- (source)
Input signal 0/4 ... 20 mA
Voltage drop terminals 3, 4: ≤ 6.1 V at 20 mA
Short-circuit current terminals 1+, 2-: 25 mA
Input resistance terminals 1+, 2-: max. 500 Ω (BRAIN)
(250 Ω load)
Available voltage terminals 1+, 2-: ≥ 16 V at 20 mA , ≥ 18.5 V at 4 mA


Output of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Connection side control side
Connection source: terminals 5-, 6+; 7-, 8+
sink: terminals 5+, 6-, 7+, 8-
Load channel 1: 0 ... 500 Ω (20 mA)/> 1 MΩ (5 V)
channel 2: 0 ... 500 Ω (20 mA)/> 1 MΩ (5 V)
Output signal 0/4 ... 20 mA or 0/1 ... 5 V
Ripple max. 50 µA rms


Transfer characteristics of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Deviation Iout < 20 µA (0.1 %); Vout < 10 mV (0.2 %) incl. calibration, linearity, hysteresis and fluctuation of supply voltage, at 20 °C (68 °F), 0/4 ... 20 mA, 0/1 ... 5 V
Influence of ambient temperature current output: 0.25 µA/K
voltage output: 80 µV/K
Frequency range field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 6 kHz (-3 dB)
control side into the field side: bandwidth with 0.5 Vpp signal 0.3 ... 6 kHz (-3 dB)
Settling time 6 ms
Rise time/fall time 2 ms


Galvanic isolation of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Output/power supply functional insulation, rated insulation voltage 50 V AC
Output/Output functional insulation, rated insulation voltage 50 V AC


Indicators/settings of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Display elements LED
Control elements DIP-switch
Configuration via DIP switches
Labeling space for labeling at the front


Directive conformity of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)


Conformity of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Electromagnetic compatibility NE 21:2012
EN 61326-3-2:2008
Degree of protection IEC 60529:2001
Protection against electrical shock UL 61010-1:2012


Ambient conditions of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
extended ambient temperature range up to 70 °C (158 °F), refer to manual for necessary mounting conditions


Mechanical specifications of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Degree of protection IP20
Connection screw terminals
Mass approx. 100 g
Dimensions 12.5 x 114 x 122 mm (0.5 x 4.5 x 4.8 inch) , housing type A2
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001


Data for application in connection with hazardous areas of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

EU-type examination certificate BASEEFA 13 ATEX 0077 X
Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC
Ex-Hexagon II (1)D [Ex ia Da] IIIC
Ex-Hexagon I (M1) [Ex ia Ma] I
Input [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I
Supply
Maximum safe voltage 250 V (Attention! The rated voltage can be lower.)
Equipment terminals 1+, 2-
Voltage Uo 25.2 V
Voltage Uq 28.2 V
Current Io 93 mA
Power Po 656 mW
Internal capacitance Ci 10 nF
Internal inductance Li 0 mH
Equipment terminals 3+, 4-
Voltage Ui 30 V
Current Ii 115 mA
Power Pi 700 mW
Voltage Uo 5 V
Current Io 6.8 mA
Power Po 1.6 mW
Output
Maximum safe voltage 250 V (Attention! The rated voltage can be lower.)
Certificate BASEEFA 13 ATEX 0078 X
Marking Ex-Hexagon II 3G Ex nA II T4 Gc [device in zone 2]
Galvanic isolation
Input/Output safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Input/power supply safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010


International approvals of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

UL approval
Control drawing 116-0380 (cULus)
IECEx approval
IECEx certificate IECEx BAS 13.0043X
IECEx marking [Ex ia Ga] IIC , [Ex ia Da] IIIC , [Ex ia Ma] I


General information of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

Note Both output loads must be connected to ensure complete and correct operation within the technical specification.
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.


Classifications of Pepperl+Fuchs KCD2-STC-Ex1.2O.ES SMART Transmitter Power Supply KCD2-STC-Ex1.2O.ES Safety Barriers Arrived

System Classcode
ECLASS 11.0 27210119
ECLASS 10.0.1 27210119
ECLASS 9.0 27210119
ECLASS 8.0 27210119
ECLASS 5.1 27210119
ETIM 8.0 EC001485
ETIM 7.0 EC001485
ETIM 6.0 EC001485
ETIM 5.0 EC001485
UNSPSC 12.1 32101514
