IFM PI2798 Flush Pressure Sensors with Display PI2798 Induct

IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived







Features of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Flush pressure sensor with display
PI2798
PI-,25BREA01-MFRKG/US/ /P
Robust stainless steel housing for use in the food and beverage industry
Hygienic, flush design
Resistant to high-pressure cleaning with aggressive cleaning agents
High temperature resistance and high protection rating
Programmable analog and switching output


Technical Specification of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Product characteristics of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Output signal switching signal; analog signal; IO-Link; (configurable)
Measuring range -0.0124...0.25 bar -12.4...250 mbar -5...100.4 inH2O -1.24...25 kPa
Process connection threaded connection G 1 external thread Aseptoflex Vario


Application of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

System gold-plated contacts
Application flush mountable for the food and beverage industry
Media viscous media and liquids with suspended particles; liquids and gases
Medium temperature [°C] -25...125; (145 max. 1h)
Min. bursting pressure 30000 mbar   12044 inH2O  3000 kPa
Pressure rating         6000 mbar    2400 inH2O   600 kPa
Vacuum resistance [mbar] -1000
Type of pressure relative pressure
No dead space yes
MAWP (for applications according to CRN) [bar] 10



Electrical data of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Min. insulation resistance [MΩ] 100; (500 V DC)
Protection class III
Reverse polarity protection yes
Integrated watchdog yes


2-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Operating voltage [V] 20...32 DC
Current consumption [mA] 3.6...21
Power-on delay time [s] 1



3-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Operating voltage [V] 18...32 DC
Current consumption [mA] < 45
Power-on delay time [s] 0.5


Inputs / outputs of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Number of inputs and outputs Number of digital outputs: 2; Number of analog outputs: 1



Outputs of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Total number of outputs 2
Output signal switching signal; analog signal; IO-Link; (configurable)
Electrical design PNP/NPN
Number of digital outputs 2
Output function normally open / closed; (configurable)
Number of analog outputs 1
Analog current output [mA] 4...20, invertible; (scalable)
Short-circuit protection yes
Type of short-circuit protection yes (non-latching)
Overload protection yes


2-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Max. load [Ω] 300


3-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Max. voltage drop switching output DC [V] 2
Permanent current rating of switching output DC [mA] 250
Switching frequency DC [Hz] 125
Max. load [Ω] (Ub - 10 V) / 20 mA


Measuring/setting range of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Measuring range -0.0124...0.25 bar  -12.4...250 mbar    -5...100.4 inH2O  -1.24...25 kPa
Set point SP -12...250 mbar      -4.8...100.4 inH2O  -1.2...25 kPa
Reset point rP -12.4...249.6 mbar  -5...100.2 inH2O    -1.24...24.96 kPa
Analog start point -12.4...187.4 mbar -5...75.2 inH2O    -1.24...18.74 kPa
Analog end point 50...250 mbar  20.1...100.4 inH2O   5...25 kPa
In steps of 0.2 mbar       0.1 inH2O            0.02 kPa
Factory setting SP1 = 62.4 mbar     rP1 = 57.4 mbar
                 SP2 = 187.4 mbar    rP2 = 182.4 mbar
                 ASP = 0.0 mbar      AEP = 250.0 mbar


Accuracy / deviations of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Switch point accuracy [% of the span] < ± 0,2; (Turn down 1:1)
Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K; Turn down 1:1)
Characteristics deviation [% of the span] < ± 0,2; (Turn down 1:1 , linearity, incl. hysteresis and repeatability , limit value setting to DIN EN IEC 62828-1)
Linearity deviation [% of the span] < ± 0,15; (Turn down 1:1)
Hysteresis deviation [% of the span] < ± 0,15; (Turn down 1:1)
Long-term stability [% of the span] < ± 0,1; (Turn down 1:1; per year)
Temperature coefficient zero point [% of the span / 10 K] < ± 0,05; (0...70 °C)
Temperature coefficient span [% of the span / 10 K] < ± 0,15; (0...70 °C)



Reaction times of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Damping for the switching output dAP [s] 0...30
Damping for the analog output dAA [s] 0.01...99.99

2-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Step response time analog output [ms] 45

3-wire of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Min. response time of switching output (dAP) [ms] 3
Step response time analog output [ms] 7


Interfaces of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Communication interface IO-Link
Transmission type COM2 (38,4 kBaud)
IO-Link revision 1.0
Profiles no profile
SIO mode yes
Required master port class A
Process data analog 1
Process data binary 2
Min. process cycle time [ms] 2.3
Supported DeviceIDs Type of operation    DeviceID
                                             default             257



Operating conditions of IFM PI2798 Flush Pressure Sensors with Display PI2798 Inductive Sensors Arrived

Ambient temperature [°C] -25...80
Storage temperature [°C] -40...100
Protection IP 67; IP 68; IP 69K
