Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multim

Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived





Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Selected model features
Fluke 325 (model shown)

Fluke 325 True-RMS Clamp Meter

(Images may not reflect the selected model)

Key features of Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

True-rms AC/DC current, voltage, temperature, frequency
Clamp meter, test leads, K-type thermocouple and soft case
Versatile tool performs most front-line measurement tasks



Product overview: Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Troubleshoot problems safely and accurately

The Fluke 325 True-rms Clamp Meter is a reliable, versatile troubleshooting tool for commercial and residential electricians. Featuring a slim design for easy transport and use, and a large display for efficient troubleshooting. In addition to true-rms AC current and voltage on non-linear loads, the 325 measures:

DC current
DC voltage
Temperature
Frequency
You’ll carry fewer tools in your bag and get more work done.

Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Covers most problems you see day-in, day-out

The 325 gives you a strong combination of measurement functions, in a tool that is reliable, easy-to-use and affordable. This clamp meter offers True-rms AC voltage and current measurements on non-linear signals. Paired with the CAT III 600 V, CAT IV 300 V safety rating the clamp meter can also measure:

* Measures AC/DC current up to 400 A through jaw
* AC/DC voltage to 600 V using test leads
* Measures frequency from 5 Hz to 500 Hz; resistance to 40 kΩ
* Measures temperature from -10 °C to 400 °C with included K-type thermocouple
* Min/Max function records important values
* Comes with a two-year warranty



What's in the box:  Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Fluke 325 True-RMS Clamp Meter
TL75 Test Leads
Type K Thermocouple
Two AAA Batteries (Installed)
Soft Case


Technical Specifications: Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Specifications

AC current Range 40.00 A / 400.0 A
Accuracy 2% ± 5 digits (45 Hz to 65 Hz)
2.5% ± 5 digits (65 Hz to 400 Hz)
DC current Range 40.00 A / 400.0 A
Accuracy 2% ± 5 digits
AC voltage Range 600.0 V
Accuracy 1.5% ± 5 digits
DC voltage Range 600.0 V
Accuracy 1.0% ± 5 digits
Resistance Range 400.0 Ω / 4000 Ω / 40.00 kΩ
Accuracy 1.0% ± 5 digits
Continuity ≤ 30 Ω
Capacitance 0 to 100.0 μF / 100μF to 1000 μF
Frequency 5.0 Hz to 500.0 Hz
AC response True-RMS
Backlight Yes
Data hold Yes
Contact temperature -10.0°C to 400.0°C (14.0°F to 752.0°F)
Min/Max Yes
Size H x W x D (mm) 207 x 75 x 34
Max wire diameter 30 mm (600 MCM)
Weight 283 g
Category rating CAT III 600 V
CAT IV 300 V
Warranty Two-year


Models: Fluke 325 True RMS Clamp Meters Fluke 325 AC/DC Clamp Multimeters Arrived

Fluke 325Fluke 325 True-RMS Clamp Meter

Includes:

Fluke 325 True-RMS Clamp Meter
TL75 Test Leads
Type K Thermocouple
Two AAA Batteries (Installed)
Soft Case
Fluke 325 CAL

Fluke 325 True RMS Clamp Meter, with a traceable certificate of calibration with data from Fluke
