E+H FMR50 vs FMR51 vs FMR52: How to Select the Right Micropilot

When engineers search for an Endress+Hauser Micropilot FMR50, FMR51 or FMR52, the model numbers can look very similar. However, the correct selection should be based on the actual process, installation environment, required approvals and measurement conditions.

The FMR50/FMR51/FMR52 family is covered by Endress+Hauser technical documentation for free-space radar measurement.

FMR50, FMR51 and FMR52 — What Should Engineers Compare?

Rather than selecting a transmitter simply because the model number looks similar, engineers should compare the following parameters:

Selection factor	What to check
Medium	Liquid, corrosive liquid, hygienic process, etc.
Process temperature	Actual operating temperature
Process pressure	Normal and maximum pressure
Antenna	Required antenna and material
Process connection	Flange, threaded or hygienic connection
Measuring range	Actual tank height and required range
Communication	HART, PROFIBUS PA or other required interface
Approval	Hazardous-area, hygienic or other project requirements
Installation	Nozzle, tank geometry and internal obstructions

The key point is that FMR50, FMR51 and FMR52 should not be treated as interchangeable simply because they belong to the same Micropilot family.

FMR52 vs Other Level Measurement Technologies

Radar level measurement is only one of several technologies available to process engineers.

Radar vs ultrasonic:
Radar is often considered when process conditions, vapor or other environmental factors make ultrasonic measurement less suitable. The actual application conditions should determine the final technology choice.

Radar vs guided wave radar:
Free-space radar measures through the open space between the transmitter and product surface, while guided wave radar uses a probe or cable. Free-space radar can be attractive where a non-contact measurement method is preferred.

Radar vs differential pressure:
Differential-pressure level measurement relies on pressure relationships and may involve impulse lines or wetted components. Radar provides a different measurement principle and can reduce the need for direct mechanical contact with the process medium.

Why FMR52 May Be Selected

For a process engineer evaluating FMR52, several practical questions are more important than the model name itself:

• Is non-contact measurement required?

• What is the process medium?

• Are there corrosive or hygienic requirements?

• What are the operating temperature and pressure?

• Is the tank equipped with an agitator or internal structures?

• Which communication protocol is required?

• Are special approvals required?

• Does the new transmitter need to replace an existing installation?

Once these questions are answered, the appropriate Micropilot configuration can be determined more accurately.

The Most Important Rule for Model Selection

When ordering an E+H FMR52, do not select the instrument based only on "FMR52."

The complete order code, process connection, antenna configuration, communication protocol and required approvals should be checked against the application.

Endress+Hauser's official documentation provides technical information and operating instructions for the FMR51/FMR52 family, making the manufacturer's documentation an important reference during engineering and procurement.

For replacement projects, the most reliable starting point is usually the existing nameplate or complete order code. This allows the new configuration to be compared with the installed instrument before the purchase is finalized.

Keywords: E+H FMR52, FMR50 vs FMR51 vs FMR52, FMR52 selection, Micropilot FMR52, radar level transmitter, Endress Hauser FMR52
