Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
HARDWARE SPECIFICATIONS of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
For the installation specifications and the environmental conditions common to the systems, refer to “Integrated Production Control System CENTUM VP System Overview (Vnet/IP Edition)” (GS 33K01A10-50E).
Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Processor:VR5532 (350 MHz)
Main Memory Capacity:128 MB
Memory Protection During Power Failure
Battery
Battery Back-up for Main Memory: Max. 72 hours
Battery Recharge Time: Min. 48 hours
FCU Status Contact Output of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
2 terminals (NC, C)
Contact Points open during FCU failure
Contact Rating: 30 V DC, max. 0.3 A
Note: When option code /HKU is specified, a FCU fault
contact is output from the House Keeping Unit
(HKU).
Communication Interface of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Vnet/IP Interface: Dual-redundant
HKU Interface (Option)
When option code /HKU is specified, a FCU
fault contact is output from the HKU. Also, the
environmental conditions of the cabinet connected via
the HK bus and optical ESB bus can be monitored and
the operating status of the HKU can be displayed on
the HIS. System alarms can also be displayed.
Power Supply of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Voltage: 100-120 V AC, Frequency: 50/60 Hz
Voltage: 220-240 V AC, Frequency: 50/60 Hz
Voltage: 24 V DC
Specify with the Suffix Code.
Power Consumption of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
100-120 V AC: 200 VA
220-240 V AC: 230 VA
24 V DC: 5.5 A
Weight of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Approx. 7 kg (AFV30S)
Approx. 8 kg (AFV30D)
Module configuration of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Power Supply Module (PW481 or PW482 or PW484):
2 modules modules for dual-redundant configuration.
Processor Module (CP461): 2 modules in case for dual-redundant configuration.
I/O Modules(*1): Max. 8
*1: Non-standard components.
Installation Restrictions of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
To connect the ESB Bus Node Unit (ANB10 ) or Optical ESB Bus Node Unit (ANB11 ) to the FCU, install the ESB Bus Coupler Module (EC401 or EC402) in slots 7 and 8 of the FCU. For the dual-redundant configuration of the processor modules, EC401 or EC402 must be installed in both slot 7 and slot 8. In case ESB Bus has a single configuration, EC401 or EC402 must be installed in slot 7 and keep slot 8 empty.
To install the optical ESB bus node unit and ESB bus node unit in a remote location, use the Optical ESB Bus Repeater Master Module (ANT401 or ANT411) to connect them with an optical fiber cable. To install the optical ESB bus repeater master module in the FCU, install a pair of modules in slots 1 to 6 in order from right to left according to the number of branches. In a single configuration, install the individual modules in slots 1, 3, and 5 in order from right to left. For details, see the “Optical ESB Bus Repeater Module” (GS 33K50F51-50E/GS 33K50F52-50E).
For the limitations and precautions for installing I/O modules, see “FIO System Overview (for Vnet/IP)” (GS 33K50F10-50E).
Connection of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Power Supply: M4 screw terminal connection
Grounding: M4 screw terminal connection
FCU Status Contact Output: M4 screw terminal
connection
Network: Connect UTP cable (CAT5e or better) to
Layer 2 switch.
Safety Standards
[CSA]
(for 100-120 V AC power supply)
[CE Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
EMC Conformity Standards
[CE Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
[C-Tick Marking]
(for 220-240 V AC and 24 V DC power
supply)
[KC Marking]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
Standards for Hazardous Location Equipment
[FM Non-Incendive]
(for 100-120 V AC, 220-240 V AC and 24
V DC power supply)
[Type n]
(for 24 V DC power supply)
MODELS AND SUFFIX CODES of Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
Duplexed Field Control Unit
Description
Model AFV30D Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch Rack Mountable)
Suffix
Codes
-S Standard type
4 Dual-redundant Vnet/IP, dual-redundant power supply
1 Always 1
1 100 - 120 V AC power supply (*1)
2 220 - 240 V AC power supply (*1)
4 24 V DC power supply (*1)
5 Basic type with no explosion protection
6 With ISA Standard G3 option and no explosion protection
E Basic type with explosion protection
F With ISA Standard G3 option and explosion protection
1 LFS1700 Control function for field control station
(for AFV30/AFV40, Vnet/IP and FIO) <for CP461>
Option
Codes
/HKU With HKU interface (*2)
/ATDOC Explosion Protection Manual (*3)
Note: These products are subject to the Export Administration Regulations (EAR) by the United States Department of Commerce,
Bureau of Industry and Security (BIS). It is not possible to export or reexport these products to Iran, Cuba, North Korea,
Syria, and Sudan.
*1: To meet the safety standards and EMC standards, the unit must be installed in a keyed metallic cabinet.
*2: When used in combination with ACUKT, specify this option code “/HKU.”
*3: Select the option code “/ATDOC” to follow the ATEX Directive for use in potentially explosive atmospheres.
Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
AFV30D Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch Rack Mountable)
AFV30D-S41251, AFV30D-S41251/HKU, AFV30D-S41251/ATDOC
AFV30D-S41261, AFV30D-S41261/HKU, AFV30D-S41261/ATDOC
AFV30D-S412E1, AFV30D-S412E1/HKU, AFV30D-S412E1/ATDOC
AFV30D-S412F1, AFV30D-S412F1/HKU, AFV30D-S412F1/ATDOC
AFV30D-S41151, AFV30D-S41151/HKU, AFV30D-S41151/ATDOC
AFV30D-S41161, AFV30D-S41161/HKU, AFV30D-S41161/ATDOC
AFV30D-S411E1, AFV30D-S411E1/HKU, AFV30D-S411E1/ATDOC
AFV30D-S411F1, AFV30D-S411F1/HKU, AFV30D-S411F1/ATDOC
AFV30D-S41451, AFV30D-S41451/HKU, AFV30D-S41451/ATDOC
AFV30D-S41461, AFV30D-S41461/HKU, AFV30D-S41461/ATDOC
AFV30D-S414E1, AFV30D-S414E1/HKU, AFV30D-S414E1/ATDOC
AFV30D-S414F1, AFV30D-S414F1/HKU, AFV30D-S414F1/ATDOC
AFV30S Field Control Unit (for FIO, 19-inch Rack Mountable) Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
AFV30S-S41252, AFV30S-S41252/HKU, AFV30S-S41252/ATDOC
AFV30S-S41262, AFV30S-S41262/HKU, AFV30S-S41262/ATDOC
AFV30S-S412E2, AFV30S-S412E2/HKU, AFV30S-S412E2/ATDOC
AFV30S-S412F2, AFV30S-S412F2/HKU, AFV30S-S412F2/ATDOC
AFV30S-S41152, AFV30S-S41152/HKU, AFV30S-S41152/ATDOC
AFV30S-S41162, AFV30S-S41162/HKU, AFV30S-S41162/ATDOC
AFV30S-S411E2, AFV30S-S411E2/HKU, AFV30S-S411E2/ATDOC
AFV30S-S411F2, AFV30S-S411F2/HKU, AFV30S-S411F2/ATDOC
AFV30S-S41452, AFV30S-S41452/HKU, AFV30S-S41452/ATDOC
AFV30S-S41462, AFV30S-S41462/HKU, AFV30S-S41462/ATDOC
AFV30S-S414E2, AFV30S-S414E2/HKU, AFV30S-S414E2/ATDOC
AFV30S-S414F2, AFV30S-S414F2/HKU, AFV30S-S414F2/ATDOC
AFV30S-S31252, AFV30S-S31252/HKU, AFV30S-S31252/ATDOC
AFV30S-S31262, AFV30S-S31262/HKU, AFV30S-S31262/ATDOC
AFV30S-S312E2, AFV30S-S312E2/HKU, AFV30S-S312E2/ATDOC
AFV30S-S312F2, AFV30S-S312F2/HKU, AFV30S-S312F2/ATDOC
AFV30S-S31152, AFV30S-S31152/HKU, AFV30S-S31152/ATDOC
AFV30S-S31162, AFV30S-S31162/HKU, AFV30S-S31162/ATDOC
AFV30S-S311E2, AFV30S-S311E2/HKU, AFV30S-S311E2/ATDOC
AFV30S-S311F2, AFV30S-S311F2/HKU, AFV30S-S311F2/ATDOC
AFV30S-S31452, AFV30S-S31452/HKU, AFV30S-S31452/ATDOC
AFV30S-S31462, AFV30S-S31462/HKU, AFV30S-S31462/ATDOC
AFV30S-S314E2, AFV30S-S314E2/HKU, AFV30S-S314E2/ATDOC
AFV30S-S314F2, AFV30S-S314F2/HKU, AFV30S-S314F2/ATDOC
AFV30D Duplexed Field Control Unit (for Vnet/IP and FIO, 19-inch Rack Mountable) Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
AFV30D-S41252, AFV30D-S41252/HKU, AFV30D-S41252/ATDOC
AFV30D-S41262, AFV30D-S41262/HKU, AFV30D-S41262/ATDOC
AFV30D-S412E2, AFV30D-S412E2/HKU, AFV30D-S412E2/ATDOC
AFV30D-S412F2, AFV30D-S412F2/HKU, AFV30D-S412F2/ATDOC
AFV30D-S41152, AFV30D-S41152/HKU, AFV30D-S41152/ATDOC
AFV30D-S41162, AFV30D-S41162/HKU, AFV30D-S41162/ATDOC
AFV30D-S411E2, AFV30D-S411E2/HKU, AFV30D-S411E2/ATDOC
AFV30D-S411F2, AFV30D-S411F2/HKU, AFV30D-S411F2/ATDOC
AFV30D-S41452, AFV30D-S41452/HKU, AFV30D-S41452/ATDOC
AFV30D-S41462, AFV30D-S41462/HKU, AFV30D-S41462/ATDOC
AFV30D-S414E2, AFV30D-S414E2/HKU, AFV30D-S414E2/ATDOC
AFV30D-S414F2, AFV30D-S414F2/HKU, AFV30D-S414F2/ATDOC
AFV40S Field Control Unit (for FIO, with Cabinet) Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
AFV40S-S41102,AFV40S-41102/ATDOC,AFV40S-S41102/CH,AFV40S-41102/CE
AFV40S-S41202,AFV40S-41202/ATDOC,AFV40S-S41202/CH,AFV40S-41202/CE
AFV40S-S41402,AFV40S-41402/ATDOC,AFV40S-S41402/CH,AFV40S-41402/CE
AFV40S-S42102,AFV40S-42102/ATDOC,AFV40S-S42102/CH,AFV40S-42102/CE
AFV40S-S42202,AFV40S-42202/ATDOC,AFV40S-S42202/CH,AFV40S-42202/CE
AFV40S-S42402,AFV40S-42402/ATDOC,AFV40S-S42402/CH,AFV40S-42402/CE
AFV40S-S43102,AFV40S-43102/ATDOC,AFV40S-S43102/CH,AFV40S-43102/CE
AFV40S-S43202,AFV40S-43202/ATDOC,AFV40S-S43202/CH,AFV40S-43202/CE
AFV40S-S43402,AFV40S-43402/ATDOC,AFV40S-S43402/CH,AFV40S-43402/CE
AFV40S-S44102,AFV40S-44102/ATDOC,AFV40S-S44102/CH,AFV40S-44102/CE
AFV40S-S44202,AFV40S-44202/ATDOC,AFV40S-S44202/CH,AFV40S-44202/CE
AFV40S-S44402,AFV40S-44402/ATDOC,AFV40S-S44402/CH,AFV40S-44402/CE
AFV40S-S31102,AFV40S-41102/ATDOC,AFV40S-S31102/CH,AFV40S-41102/CE
AFV40S-S31202,AFV40S-41202/ATDOC,AFV40S-S31202/CH,AFV40S-41202/CE
AFV40S-S31402,AFV40S-41402/ATDOC,AFV40S-S31402/CH,AFV40S-41402/CE
AFV40S-S32102,AFV40S-42102/ATDOC,AFV40S-S32102/CH,AFV40S-42102/CE
AFV40S-S32202,AFV40S-42202/ATDOC,AFV40S-S32202/CH,AFV40S-42202/CE
AFV40S-S32402,AFV40S-42402/ATDOC,AFV40S-S32402/CH,AFV40S-42402/CE
AFV40S-S33102,AFV40S-43102/ATDOC,AFV40S-S33102/CH,AFV40S-43102/CE
AFV40S-S33202,AFV40S-43202/ATDOC,AFV40S-S33202/CH,AFV40S-43202/CE
AFV40S-S33402,AFV40S-43402/ATDOC,AFV40S-S33402/CH,AFV40S-43402/CE
AFV40S-S34102,AFV40S-44102/ATDOC,AFV40S-S34102/CH,AFV40S-44102/CE
AFV40S-S34202,AFV40S-44202/ATDOC,AFV40S-S34202/CH,AFV40S-44202/CE
AFV40S-S34402,AFV40S-44402/ATDOC,AFV40S-S34402/CH,AFV40S-44402/CE
AFV40D Duplexed Field Control Unit (for FIO, with Cabinet) Yokogawa AFV30D-S41251/HKU AFV30D-S41251/ATDOC AFV30D Field Control Unit
AFV40D-S421102, AFV40D-421102/ATDOC, AFV40D-S421102/CH, AFV40D-421102/CE
AFV40D-S421202, AFV40D-421202/ATDOC, AFV40D-S421202/CH, AFV40D-421202/CE
AFV40D-S421402, AFV40D-421402/ATDOC, AFV40D-S421402/CH, AFV40D-421402/CE
AFV40D-S422102, AFV40D-422102/ATDOC, AFV40D-S422102/CH, AFV40D-422102/CE
AFV40D-S422202, AFV40D-422202/ATDOC, AFV40D-S422202/CH, AFV40D-422202/CE
AFV40D-S422402, AFV40D-422402/ATDOC, AFV40D-S422402/CH, AFV40D-422402/CE
AFV40D-S441102, AFV40D-441102/ATDOC, AFV40D-S441102/CH, AFV40D-441102/CE
AFV40D-S441202, AFV40D-441202/ATDOC, AFV40D-S441202/CH, AFV40D-441202/CE
AFV40D-S441402, AFV40D-441402/ATDOC, AFV40D-S441402/CH, AFV40D-441402/CE
AFV40D-S442102, AFV40D-442102/ATDOC, AFV40D-S442102/CH, AFV40D-442102/CE
AFV40D-S442202, AFV40D-442202/ATDOC, AFV40D-S442202/CH, AFV40D-442202/CE
AFV40D-S442402, AFV40D-442402/ATDOC, AFV40D-S442402/CH, AFV40D-442402/CE
